Полный отчётТехнические параметры
| Условия эксплуатации и корпус | |
|---|---|
| Setup height | ≤4000 m |
| Storage temperature | -40 °C - 85 °C |
| Другое | |
| 07300.0-00 | Temperature, relative humidity | IP64 | Stainless steel | -40 °C - 70 °C | ± 0,2 K | 0 % RH - 100 % RH | ± 2 % | 1: t63 <120 s / 2: t63 <20 s | -40 °C - 70 °C | Male connector M12 IEC 61076-2-101, 4-pole, A-coded | incl. pipe clip for screw fixing, Ø 3 mm | Ø 20 mm | Ø 20 mm | 33,5 mm | 25 g | 244445 | 244446 | 244447 | Cable 2.0 m, fully assembled with M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 5.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 20.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded |
| 07300.1-00 | Temperature, relative humidity | IP20 | Plastic to UL94 V-0, black | -40 °C - 80 °C | ± 0,2 K | 0 % RH - 100 % RH | ± 2 % | 1: t63 <90 s / 2: t63 <7 s | -40 °C - 85 °C | Cable with male connector, shielded, 1.0 m | Clip for 35 mm DIN rail, EN 60715 and M4 screw fixing | 13 mm | 12 mm | 59 mm | 40 g |
| 07300.1-01 | Temperature, relative humidity | IP20 | Plastic to UL94 V-0, black | -40 °C - 80 °C | ± 0,2 K | 0 % RH - 100 % RH | ± 2 % | 1: t63 <90 s / 2: t63 <7 s | -40 °C - 85 °C | Cable with male connector, shielded, 2.0 m | Clip for 35 mm DIN rail, EN 60715 and M4 screw fixing | 13 mm | 12 mm | 59 mm | 70 g |
| 07301.0-00 | Absolute air pressure, temperature | IP64 | Stainless steel | 300 hPa - 1100 hPa | ± 1,0 hPa | -40 °C - 70 °C | ± 0,5 K | 1: t63 <5 s / 2: t63 <150 s | -40 °C - 70 °C | Male connector M12 IEC 61076-2-101, 4-pole, A-coded | incl. pipe clip for screw fixing, Ø 3 mm | Ø 20 mm | Ø 20 mm | 33,5 mm | 25 g | 244445 | 244446 | 244447 | Cable 2.0 m, fully assembled with M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 5.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 20.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded |
| 07302.0-00 | visible light | IP65 | Stainless steel | 0,01 lx - 83865 lx | ± 0,2 % | t90 <7 s | -40 °C - 70 °C | Male connector M12 IEC 61076-2-101, 4-pole, A-coded | incl. pipe clip for screw fixing, Ø 3 mm | Ø 20 mm | Ø 20 mm | 40 mm | 25 g | 244445 | 244446 | 244447 | Cable 2.0 m, fully assembled with M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 5.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 20.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded |
| 07303.0-00 | Air quality, temperature | IP64 | Stainless steel | 0 VOC index - 500 VOC index | -10 °C - 50 °C | ± 0,2 K | 1: t63 <10 s / 2: t63 <150 s | -10 °C - 50 °C | Male connector M12 IEC 61076-2-101, 4-pole, A-coded | incl. pipe clip for screw fixing, Ø 3 mm | Ø 20 mm | Ø 20 mm | 33,5 mm | 25 g | 244445 | 244446 | 244447 | Cable 2.0 m, fully assembled with M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 5.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded | Cable 20.0 m, for self-assembly, incl. M12 cable socket IEC 61076-2-101, 4-pole, A-coded, shielded |
| Design | SHC 071 sensor |
| Operating humidity | ≤100 % RH |
| Storage humidity | ≤90 % RH |
