Cvilux USAТайвань, Китай
6 POS 2.50MM (.098) WIRE TO BOAR
Все аналоги
Полный отчётТехнические параметры
Основные параметры
Число контактов6
Число рядов1
Шаг2.5 mm
Тип (вилка / розетка)Male
Номинальный ток3 AМакс.
| Питание | |
|---|---|
| Current Rating (Amps) | 3A |
| Voltage Rating | 50VAC |
| Условия эксплуатации и корпус | |
| Insulation Height | 0.232" (5.90mm) |
| Mated Stacking Heights | - |
| Mounting Type | Through Hole |
| Operating Temperature | -25°C~85°C |
| Package | Bag |
| Другое | |
| Applications | - |
| Base Product Number | CI2506P1 |
| Connector Type | Header |
| Contact Finish - Mating | Tin |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Mating | 120.0µin (3.05µm) |
| Contact Finish Thickness - Post | 120.0µin (3.05µm) |
| Contact Length - Mating | - |
| Contact Length - Post | 0.134" (3.40mm) |
| Contact Material | Brass |
| Contact Shape | Circular |
| Contact Type | Male Pin |
| Fastening Type | Detent Lock |
| Features | - |
| Ingress Protection | - |
| Insulation Color | Natural |
| Insulation Material | Polyamide (PA46), Nylon 4/6 |
| Material Flammability Rating | UL94 V-0 |
| Mfr | Cvilux USA |
| Number of Positions | 6 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Overall Contact Length | 0.350" (8.89mm) |
| Pitch - Mating | 0.098" (2.50mm) |
| Product Status | Obsolete |
| Row Spacing - Mating | - |
| Series | CI25 |
| Shrouding | Shrouded - 4 Wall |
| Style | Board to Cable/Wire |
| Termination | Solder |
