MLT-RNG 150V/10A/600W DC PS
Все аналоги
Полный отчётТехнические параметры
| Питание | |
|---|---|
| Current - Output | 0 ~ 10A |
| Power (Watts) | 600W |
| Voltage - Output | 0 ~ 150VDC |
| Voltage - Supply | 110VAC, 220VAC |
| Характеристики по постоянному и переменному току | |
| Accuracy - Voltmeter; Ammeter | 0.03% + 20mV; 0.1% + 25mA |
| Current Regulation - Line | 0.05% + 10mA |
| Current Regulation - Load | 0.05% + 10mA |
| Ripple | 50mV p-p |
| Voltage Regulation - Line | 0.01% + 15mV |
| Voltage Regulation - Load | 0.01% + 15mV |
| Условия эксплуатации и корпус | |
| Package | Box |
| Size / Dimension | 17.520" L x 8.450" W x 3.470" H (445.01mm x 214.63mm x 88.14mm) |
| Другое | |
| Display Type | VFD |
| Features | Memory, Programmable, GPIB, RS232, and USB Interface |
| Mfr | B&K Precision |
| Number of Characters | 5 (2) |
| Number of Outputs | 1 |
| Product Status | Obsolete |
| Series | 9200 |
| Type | Bench (AC to DC) |
| Weight | 33 lbs (15 kg) |
