TI’s TMP112 is a ±0.5°C 1.4V-to-3.6V digital temperature sensor with I²C/SMBus. Find parameters, ordering and quality information
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Remote channels (#) | 0 |
| Supply current (max) (µA) | 10 |
| AC and DC characteristics | |
| Local sensor accuracy (max) | 0.1, 0.5, 1 |
| Environment and package | |
| Operating temperature range (°C) | -40 to 125 |
| Temp resolution (max) (bps) | 12 |
| Other | |
| Addresses | 4, 8 |
| Features | ALERT, NIST traceable, One-shot conversion |
| Interface type | I2C, SMBus |
| Rating | Catalog |
| Type | Local |
