GCTВеликобритания
06W, 1MM FFC CON, VERT, H5.5MM,
Все аналоги
Полный отчётТехнические параметры
Основные параметры
Число контактов6
Шаг1 mm
Номинальный ток1 AМакс.
| Питание | |
|---|---|
| Current Rating (Amps) | 1A |
| Voltage Rating | 125V |
| Условия эксплуатации и корпус | |
| Height Above Board | 0.217" (5.50mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~85°C |
| Package | Tape & Reel (TR) |
| Другое | |
| Actuator Color | Brown |
| Actuator Material | Polyphenylene Sulfide (PPS) |
| Cable End Type | Straight |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Contact Material | Phosphor Bronze |
| Features | Zero Insertion Force (ZIF) |
| FFC, FCB Thickness | 0.30mm |
| Flat Flex Type | FFC, FPC |
| Housing Color | Natural |
| Housing Material | Polyamide (PA6T), Nylon 6T |
| Locking Feature | Slide Lock |
| Material Flammability Rating | UL94 V-0 |
| Mating Cycles | 20 |
| Mfr | GCT |
| Number of Positions | 6 |
| Pitch | 0.039" (1.00mm) |
| Product Status | Active |
| Series | FFC3A20 |
| Termination | Solder |
