View full reportTechnical parameters
| Environment and package | |
|---|---|
| Operating temperature | -20 °C / +50 °C |
| Type of mounting | vertical, Sound outlet opening at bottom |
| Other | |
| Cable entry | 4,5-12 mm |
| Connection technology | Terminal up to 2,5 mm² |
| Degree of protection | IP65 |
| Drive system | non-polarised electromagnet, tappet strikes the membranes between 100 and 120 times/sec; DC with electrical contact breaker |
| Duty cycle | 100 % |
| Housing | Die-cast aluminium, epoxy powder-coated |
| Tone | Steady tone |
| Volume | 108 dB |
| Weight | 1,6 kg |
