View full reportTechnical parameters
| Power | |
|---|---|
| Control voltage U S | 24/110 V acc. to UIC |
| Input voltage range to UIC 550 | 0 … 3,000 V AC, 16 2/3 … 50 Hz; 0 … 5,000 V DC |
| Power input from battery | <3 mA, typical |
| Threshold voltage | >670 V AC, 16 2/3 … 50 Hz; >610 V DC |
| Environment and package | |
| Dimensions (L x W x H) | 160 x 185 x 38 mm |
| Temperature range | -40 °C … +85 °C |
| Other | |
| Ingress protection rating, IEC 60529 | IP20 |
| Max. switching capacity; Potential-free relay contact | U = 24 V DC: 4.0 A; U = 110 V DC: 0.2 A |
| Vibration, Shock | IEC 61373 |
