View full reportTechnical parameters
Key specs
Resistance100 mΩ
Tolerance100 m%
Power2 W
Temperature coefficient15 ppm/°C
| Power | |
|---|---|
| Power (Watts) | 2W |
| Environment and package | |
| Height - Seated (Max) | 0.035" (0.89mm) |
| Operating Temperature | -65°C ~ 170°C |
| Package / Case | Nonstandard |
| Size / Dimension | 0.360" L x 0.370" W (9.14mm x 9.40mm) |
| Supplier Device Package | - |
| Temperature Coefficient | ±15ppm/°C |
| Other | |
| Composition | Metal Foil |
| Failure Rate | - |
| Features | Current Sense, Moisture Resistant |
| Mfr | VPG Foil Resistors |
| Number of Terminations | 4 |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Active |
| Resistance | 100 mOhms |
| Series | CSM |
| Tolerance | ±0.1% |
