WeEn SemiconductorsNetherlands
DIODE SIL CARB 650V 20A TO247-2
All alternatives
View full reportTechnical parameters
Key specs
Reverse voltage650 V
Average rectified current20 A
Forward voltage1.4 VMax · 20 A
TypeSchottky
| Power | |
|---|---|
| Current - Average Rectified (Io) | 20A |
| Current - Reverse Leakage @ Vr | 100 µA @ 650 V |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Voltage - Forward (Vf) (Max) @ If | 1.4 V @ 20 A |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature - Junction | 175°C |
| Package | Tube |
| Package / Case | TO-247-2 |
| Supplier Device Package | TO-247-2 |
| Other | |
| Base Product Number | WNSC6 |
| Capacitance @ Vr, F | 1.2nF @ 1V, 1MHz |
| Diode Type | Silicon Carbide Schottky |
| Mfr | WeEn Semiconductors |
| Product Status | Active |
| Reverse Recovery Time (trr) | 0 ns |
| Series | - |
| Speed | No Recovery Time > 500mA (Io) |
