WeEn SemiconductorsNetherlands
DIODE SIL CARB 650V 16A TO220AC
All alternatives
View full reportTechnical parameters
Key specs
Reverse voltage650 V
Average rectified current16 A
Forward voltage1.45 VMax · 16 A
TypeSchottky
| Power | |
|---|---|
| Current - Average Rectified (Io) | 16A |
| Current - Reverse Leakage @ Vr | 80 µA @ 650 V |
| Voltage - DC Reverse (Vr) (Max) | 650 V |
| Voltage - Forward (Vf) (Max) @ If | 1.45 V @ 16 A |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature - Junction | 175°C |
| Package | Tube |
| Package / Case | TO-220-2 |
| Supplier Device Package | TO-220AC |
| Other | |
| Base Product Number | WNSC6 |
| Capacitance @ Vr, F | 780pF @ 1V, 1MHz |
| Diode Type | Silicon Carbide Schottky |
| Mfr | WeEn Semiconductors |
| Product Status | Active |
| Reverse Recovery Time (trr) | 0 ns |
| Series | - |
| Speed | No Recovery Time > 500mA (Io) |
