View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 2.3A |
| Power (Watts) | 1700W |
| Voltage Range | 380 ~ 480VAC |
| Voltage - Rated | 480VAC |
| AC and DC characteristics | |
| Noise | - |
| Environment and package | |
| Operating Temperature | -13 ~ 158°F (-25 ~ 70°C) |
| Size / Dimension | Square - 850mm L x 850mm H |
| Other | |
| Air Flow | 12000 CFM (336.0m³/min) |
| Approval Agency | CSA, EAC, UL |
| Base Product Number | W3G710 |
| Bearing Type | - |
| Fan Type | Tubeaxial |
| Features | Electronic Commutation (EC) |
| Ingress Protection | IP54 - Dust Protected, Water Resistant |
| Manufacturer | ebm-papst Inc. |
| Material - Blade | Aluminum |
| Material - Frame | Aluminum |
| Packaging | Bulk |
| Part Status | Obsolete |
| RPM | 1030 RPM |
| Series | Green Tech W3G710 |
| Static Pressure | - |
| Termination | - |
| Weight | 85 lbs (38.6 kg) |
| Width | 272.0mm |
