VersaLogic CorporationUnited States
VORTEX86DX2 CPU 1GHZ 1GB
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Power (Watts) | 6.5W |
| Environment and package | |
| Operating Temperature | 0°C~60°C |
| Package | Box |
| Size / Dimension | 5.750" x 8.000" (146.05mm x 203.20mm) |
| Other | |
| Analog Input:Output | 8:0 |
| Cooling Type | - |
| Core Processor | Vortex86DX2 |
| Digital I/O Lines | 32 |
| Ethernet | 10/100Mbps (2) |
| Expansion Site/Bus | PC/104-Plus |
| Form Factor | EBX |
| Mfr | VersaLogic Corporation |
| Number of Cores | 1 |
| Product Status | Obsolete |
| RAM Capacity/Installed | 1GB/0GB |
| RS-232 (422, 485) | 4 |
| Series | Anaconda |
| Speed | 933MHz |
| Storage Interface | SATA, Mini PCIe/mSATA, microSD |
| USB | USB 2.0 (5) |
| Video Outputs | VGA, LVDS |
| Watchdog Timer | Yes |
