Key specs
Input voltage10.8 ~ 13.2 V
Output voltage-470 V
Output current5.6 mAMax
Power2.6 WMax
IsolationNon-isolated
| Power | |
|---|---|
| Current - Output (Max) | 5.6mA |
| Power (Watts) | 2.6 W |
| Voltage - Input (Max) | 13.2V |
| Voltage - Input (Min) | 10.8V |
| Voltage - Output 1 | -470V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -10°C ~ 60°C |
| Package / Case | 7-SIP Module |
| Size / Dimension | 4.33" L x 0.47" W x 0.78" H (110.0mm x 12.0mm x 19.8mm) |
| Other | |
| Applications | ITE (Commercial) |
| Base Product Number | VHV12 |
| Control Features | Enable, Active High |
| Efficiency | - |
| Features | Remote On/Off, OCP |
| Mfr | Volgen + Furuno |
| Number of Outputs | 1 |
| Packaging | Tray |
| Part Status | Active |
| Series | VHV (3W) |
| Type | High Voltage - Non-Isolated Module |
