Vox Power Ltd.United Kingdom
AC/DC CONVERTER
All alternatives
View full reportTechnical parameters
Key specs
Input voltage85 ~ 264 V
Output voltage48 V
Output current3.75 AMax
Power425 WMax
Outputs3
| Power | |
|---|---|
| Current - Output 1 | 3.75 A |
| Current - Output 2 | 25 A |
| Current - Output 3 | 15 A |
| Power (Watts) | 425W |
| Voltage - Input | 85 ~ 264 VAC, 120 ~ 370 VDC |
| Voltage - Isolation | 4 kV |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | 5V |
| Voltage - Output 3 | 12V |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C~70°C |
| Package | Box |
| Size / Dimension | 7.00" L x 4.00" W x 1.57" H (177.8mm x 101.6mm x 40.0mm) |
| Other | |
| Applications | Medical |
| Approval Agency | CB, CE, CSA, UL |
| Base Product Number | VCCM600 |
| Efficiency | 90% |
| Features | Adjustable Output, Load Sharing, PFC, Remote Sense, Universal Input |
| Mfr | Vox Power Ltd. |
| Minimum Load Required | No |
| Number of Outputs | 3 |
| Product Status | Active |
| Series | VCCM600M |
| Standard Number | 60601-1 |
| Type | Open Frame |
