V625LA80CP
Littelfuse Inc.United States

V625LA80CP

ActiveVaristors, MOVs

VARISTOR 1KV 10KA DISC 20MM

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Key specs

Varistor voltage1 kV
Max AC voltage625 VMax
Surge current10 kAMax
Energy490 JMax
Power
Current - Surge10 kA
Varistor Voltage (Max)1.1 kV
Varistor Voltage (Min)900 V
Varistor Voltage (Typ)1 kV
AC and DC characteristics
Capacitance @ Frequency120 pF @ 1 MHz
Environment and package
Mounting TypeThrough Hole
Operating Temperature-55°C ~ 85°C (TA)
PackageBulk
Package / CaseDisc 20mm
Other
Energy490J
Maximum AC Volts625 V
MfrLittelfuse Inc.
Number of Circuits1
Product StatusActive
SeriesC-III

Documents

DatasheetDatasheet · 862.8 KB · 2026-09-22Application NoteApplication Note · 1.5 MB · 2026-09-22Application NoteApplication Note · 645.4 KB · 2026-09-22Application NoteApplication Note · 305.8 KB · 2026-09-22Application NoteApplication Note · 163.6 KB · 2026-09-22Application NoteApplication Note · 94.1 KB · 2026-09-22Application NoteApplication Note · 81.9 KB · 2026-09-22EnvironmentalEnvironmental · 51.6 KB · 2026-09-22EnvironmentalEnvironmental · 37.2 KB · 2026-09-22
Open document center
