UPL2000-D20
ActiveExplore the UPL2000-D20 RF & Microwave Connectors from Cinch. View specs, download models, request a quote, and check stock. Highly reliable connectivity solutions that support engineers’ designs. Order now for seamless integration and enduring reliability.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Working Voltage (Vrms) | 500 |
| AC and DC characteristics | |
| Impedance (Ohms) | 75 |
| Max Frequency (GHz) | 4 |
| Environment and package | |
| Mounting Style | Cable Mount |
| Operating Temp. Range (°C) | -40 to +85 |
| Other | |
| Body Finish | Nickel |
| Body Material | Brass |
| Body Style | Straight |
| Brand | Trompeter RF Connectivity |
| Cable Type | 1505F |
| Contact Material | Brass |
| Contact Plating | Gold |
| Durability (Cycles Min) | 500 |
| Gender | Plug |
| Insertion Loss (dB Max) | 0.2 |
| Insulator | PTFE |
| Number of Ports | 1 |
| Series | BNC |
| Termination Style | Cable |
| Termination Type | Full Crimp |
| Type | Standard |
