NichiconJapan
CAP ALUM 2200UF 20% 25V RADIAL
All alternatives
View full reportTechnical parameters
Key specs
Capacitance2.2 mF
Rated voltage25 V
Tolerance20 %
Lifetime10 kh105°C
| Power | |
|---|---|
| Voltage - Rated | 25 V |
| AC and DC characteristics | |
| Impedance | 14 mOhms |
| Ripple Current @ High Frequency | 3.575 A @ 100 kHz |
| Environment and package | |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Lifetime @ Temp. | 10000 Hrs @ 105°C |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~105°C |
| Package | Bulk |
| Package / Case | Radial, Can |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Surface Mount Land Size | - |
| Other | |
| Applications | General Purpose |
| Capacitance | 2200 µF |
| ESR (Equivalent Series Resistance) | - |
| Lead Spacing | 0.295" (7.50mm) |
| Mfr | Nichicon |
| Polarization | Polar |
| Product Status | Not For New Designs |
| Ratings | - |
| Series | UHW |
| Tolerance | ±20% |
