View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 0.036A |
| Power (Watts) | 100 mW |
| Voltage Range | 2 ~ 3.5VDC |
| Voltage - Rated | 3VDC |
| AC and DC characteristics | |
| Noise | 30.0dB(A) |
| Environment and package | |
| Lifetime @ Temp. | - |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Size / Dimension | Square - 15mm L x 15mm H |
| Other | |
| Air Flow | 0.309 CFM (0.009m³/min) |
| Approval Agency | CE |
| Base Product Number | UF3F3 |
| Bearing Type | Vapo-Bearing™ |
| Fan Type | Tubeaxial |
| Features | Auto Restart, Speed Sensor (Tach) |
| Ingress Protection | IP55 - Dust Protected, Water Resistant |
| Material - Blade | Liquid Crystal Polymer (LCP) |
| Material - Frame | Liquid Crystal Polymer (LCP) |
| Mfr | Sunon Fans |
| Packaging | Tray |
| Part Status | Obsolete |
| RPM | 14500 RPM |
| Series | MagLev® UF, Mighty Mini |
| Static Pressure | 0.082 in H2O (20.4 Pa) |
| Termination | 3 Wire Leads |
| Weight | 0.003 lb (1.36 g) |
| Width | 3.00mm |
