Texas InstrumentsUnited States
SWITCHING CONTROLLER
All alternatives
View full reportTechnical parameters
Key specs
TopologyBuck-boost
Outputs1
Switching frequency500 kHz
| AC and DC characteristics | |
|---|---|
| Frequency - Switching | Up to 500kHz |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | 0°C~70°C(TA) |
| Package | Bulk |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Other | |
| Clock Sync | No |
| Control Features | Frequency Control |
| Duty Cycle (Max) | 97% |
| Function | Step-Up, Step-Down, Step-Up/Step-Down |
| Mfr | Texas Instruments |
| Number of Outputs | 1 |
| Output Configuration | Positive, Isolation Capable |
| Output Phases | 1 |
| Output Type | Transistor Driver |
| Product Status | Active |
| Serial Interfaces | - |
| Series | - |
| Synchronous Rectifier | No |
| Topology | Boost, Buck, Buck-Boost, Flyback, Forward |
