The TW12BLK13 Joystick features versatile output options (5V-45V), a sleek black design, and durable 28AWG PTFE termination for reliable connections and precise control.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Overvoltage Max | 20V |
| Return to Center Voltage (No Load) | ±200mV |
| Supply Voltage Range | 5V ± .250V |
| AC and DC characteristics | |
| Output Impedance | 2Ω |
| Resolution | 1.22mV |
| Environment and package | |
| Operating Temperature | -40ºC to +85ºC (-40ºF to +185ºF) |
| Storage Temperature | -40ºC to +85ºC (-40ºF to +185ºF) |
| Other | |
| Actuator Colours | Black |
| EMC Emissions Level | EN61000-6-3:2001 |
| EMC Immunity Level | EN61000-4-3 (extended) |
| Error Signal | 1.0% |
| ESD | EN61000-4-2 (extended) |
| General Specifications | 1 or 2 axis |
| Model | Without Tab |
| Reverse Polarity Max | -10V |
| Sealing | IP67* |
| Sensor | Hall effect |
