Key specs
Current rating6 AMax
Voltage rating125 VMax
| Power | |
|---|---|
| Current Rating (Amps) | 6A (AC) |
| Voltage Rating - AC | 125 V |
| Environment and package | |
| Mounting Type | Panel Mount |
| Package | Box |
| Panel Cutout Dimensions | Circular - 10.30mm Dia |
| Other | |
| Actuator Length | 15.60mm |
| Actuator Type | Flatted (6mm Dia) |
| Angle of Throw | 30° |
| Circuit per Deck | SP11T |
| Contact Finish | - |
| Contact Material | Phosphor Bronze |
| Contact Timing | Non-Shorting (BBM) |
| Depth Behind Panel | 22.00mm |
| Features | - |
| Index Stops | Adjustable |
| Mfr | NKK Switches |
| Number of Decks | 1 |
| Number of Poles per Deck | 1 |
| Number of Positions | 2 ~ 11 |
| Product Status | Obsolete |
| Series | TS |
| Termination Style | Screw Terminal |
