Touchstone SemiconductorUnited States
IC OPAMP GP 4 CIRCUIT 14TSSOP
All alternatives
View full reportTechnical parameters
Key specs
Supply voltage650 mV ~ 2.5 V
Gain bandwidth product4 kHzTyp
Input offset voltage500 µVTyp
Quiescent current2.4 µATyp
Channels4
| Power | |
|---|---|
| Current - Input Bias | 25 pA |
| Current - Output / Channel | 1.5 mA |
| Current - Supply | 2.4µA (x4 Channels) |
| Voltage - Supply Span (Max) | 2.5 V |
| Voltage - Supply Span (Min) | 0.65 V |
| AC and DC characteristics | |
| Gain Bandwidth Product | 4 kHz |
| Slew Rate | 0.0015V/µs |
| Voltage - Input Offset | 500 µV |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TSSOP |
| Other | |
| Amplifier Type | General Purpose |
| Mfr | Touchstone Semiconductor |
| Number of Circuits | 4 |
| Output Type | Rail-to-Rail |
| Product Status | Obsolete |
| Series | - |
