View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 1.25A |
| Current - Supply | 55 µA |
| Voltage - Supply | 2.8V ~ 5.5V |
| AC and DC characteristics | |
| Delay Time - OFF | 5 ms |
| Delay Time - ON | 1 ms |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~85°C |
| Package | Tube |
| Package / Case | 8-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 8-TSSOP |
| Other | |
| Applications | Handheld/Mobile Devices |
| Base Product Number | TPS2111 |
| FET Type | N-Channel |
| Internal Switch(s) | Yes |
| Mfr | Texas Instruments |
| Product Status | Discontinued at Digi-Key |
| Ratio - Input:Output | 2:1 |
| Series | - |
| Type | Source Selector Switch |
Documents
No documents are linked to this part yet.
