Tycon Systems Inc.United States
DC/DC CONVERTER 56V 70W
All alternatives
View full reportTechnical parameters
Key specs
Input voltage10 ~ 60 V
Output voltage56 V
Output current1.25 AMax
Power70 WMax
| Power | |
|---|---|
| Current - Output (Max) | 1.25A |
| Power (Watts) | 70W |
| Voltage - Input (Max) | 60V |
| Voltage - Input (Min) | 10V |
| Voltage - Output 1 | 56V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Environment and package | |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C~70°C |
| Package | Box |
| Size / Dimension | 4.60" L x 3.50" W x 1.57" H (116.8mm x 88.9mm x 39.9mm) |
| Other | |
| Applications | ITE (Commercial) |
| Approval Agency | FCC, TUV |
| Base Product Number | TP-DCDC |
| Efficiency | 80% |
| Mfr | Tycon Systems Inc. |
| Number of Outputs | 1 |
| Product Status | Obsolete |
| Series | TP-DCDC |
| Type | Enclosed |
