View full reportTechnical parameters
| Deflection Angle | 80° |
| Diameter - Outside | 0.500" (12.70mm) |
| Finish | None |
| Leg Length | 2.000" (50.80mm) |
| Mandrel Diameter | 0.310" (7.87mm) |
| Manufacturer | Century Spring Corp |
| Material | Music Wire |
| Number of Coils | 4.25 |
| Packaging | Box |
| Part Status | Active |
| Series | - |
| Wind Direction | Right |
| Wire Diameter | 0.059" (1.50mm) |
Documents
No documents are linked to this part yet.
