View full reportTechnical parameters
| Deflection Angle | 143° |
| Diameter - Outside | 0.170" (4.32mm) |
| Finish | None |
| Leg Length | 0.500" (12.70mm) |
| Mandrel Diameter | 0.110" (2.79mm) |
| Manufacturer | Century Spring Corp |
| Material | Stainless Steel |
| Number of Coils | 4 |
| Packaging | Box |
| Part Status | Active |
| Series | - |
| Wind Direction | Left |
| Wire Diameter | 0.012" (0.30mm) |
Documents
No documents are linked to this part yet.
