Analog Devices Inc.United States
THERMOSTAT PROG ACTIVE HI TO99-8
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 50mA |
| Current - Supply | 500µA |
| Voltage - Supply | 4.5 V ~ 13.2 V |
| AC and DC characteristics | |
| Accuracy | ±1°C |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 125°C |
| Package | Tube |
| Package / Case | TO-99-8 Metal Can |
| Supplier Device Package | TO-99-8 |
| Switching Temperature | Programmable |
| Trip Temperature Threshold | Cold, Hot |
| Other | |
| Base Product Number | TMP01 |
| Features | - |
| Mfr | Analog Devices Inc. |
| Output | Active High |
| Output Function | /OverTemp, /UnderTemp |
| Output Type | Open Collector |
| Product Status | Obsolete |
| Selectable Hysteresis | Yes |
| Series | - |
