Texas InstrumentsUnited States
LOW-POWER, LOW-VOLTAGE (1.65 V T
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 5mA |
| Current - Supply (Max) | 1.3µA |
| Voltage - Supply | 1.65V ~ 5.5V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~125°C(TA) |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | 4-XFDFN Exposed Pad |
| Supplier Device Package | 4-X2SON (1.1x1.4) |
| Other | |
| Features | Sleep Mode |
| Function | Omnipolar Switch |
| Mfr | Texas Instruments |
| Output Type | Push-Pull |
| Polarization | North Pole, South Pole |
| Product Status | Active |
| Sensing Range | ±2.7mT Trip, ±0.3mT Release |
| Series | - |
| Technology | Hall Effect |
| Test Condition | 25°C |
Documents
No documents are linked to this part yet.
