NXP USA Inc.Netherlands
IC TRANSCEIVER 1/1 14HVSON
All alternatives
View full reportTechnical parameters
Key specs
ProtocolCAN
Drivers/Receivers1
Data rate5 MbpsMax
Supply voltage4.5 ~ 5.5 V
| Power | |
|---|---|
| Voltage - Supply | 4.5V ~ 5.5V |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~150°C(TJ) |
| Package | Cut Tape (CT); Digi-Reel® |
| Package / Case | 14-VDFN Exposed Pad |
| Supplier Device Package | 14-HVSON (3x4.5) |
| Other | |
| Base Product Number | TJA1043 |
| Data Rate | 5Mbps |
| Duplex | - |
| Mfr | NXP USA Inc. |
| Number of Drivers/Receivers | 1/1 |
| Product Status | Obsolete |
| Protocol | CAN |
| Receiver Hysteresis | 120 mV |
| Series | Automotive, AEC-Q100 |
| Type | Transceiver |
