TIR1000
Texas InstrumentsUnited States

TIR1000

ActiveSignal Buffers, Repeaters, Splitters

The TIR1000x serial infrared (SIR) encoder and decoder is a CMOS device that encodes and decodes bit data in conformance with the IrDA specification. A transceiver device is needed to interface to the photo-sensitive diode (PIN) and the light emitting diode (LED). A UART is needed to interface to the serial data lines.

See alternativesAsk AI FAEDatasheet PDF

All alternatives

View full report

Technical parameters

Environment and package
Operating temperature range (°C)-40 to 85
Other
ProtocolsUART
RatingCatalog

Documents

DatasheetDatasheet · 841.8 KB · 2026-09-29DatasheetDatasheet · 816.4 KB · 2026-09-23Package DrawingPackage Drawing · 321.1 KB · 2026-09-23Package DrawingPackage Drawing · 47.7 KB · 2026-09-23
