View full reportTechnical parameters
Key specs
Rated current500 mA
Rated voltage250 V
Response timeSlow
Breaking capacity35 A
| Power | |
|---|---|
| Breaking Capacity @ Rated Voltage | 35A |
| Current Rating (Amps) | 500 mA |
| Voltage Rating - AC | 250 V |
| Environment and package | |
| Mounting Type | Requires Holder |
| Operating Temperature | -55°C~125°C |
| Package | Bulk |
| Package / Case | 5mm x 20mm |
| Size / Dimension | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) |
| Other | |
| Approval Agency | CSA, KC, PSE/JET, UL |
| Base Product Number | TCC |
| Color | - |
| DC Cold Resistance | 0.643 Ohms |
| Fuse Type | Cartridge, Ceramic |
| Melting I²t | 0.38 |
| Mfr | OptiFuse |
| Product Status | Active |
| Response Time | Slow Blow |
| Series | TCC |
