Microchip TechnologyUnited States
THERMOSTAT 125DEG ACT HI SOT23-5
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Current - Output (Max) | 20mA |
| Current - Supply | 17µA |
| Voltage - Supply | 2.7 V ~ 5.5 V |
| AC and DC characteristics | |
| Accuracy | ±6°C |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C~135°C |
| Package | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Package / Case | SC-74A, SOT-753 |
| Supplier Device Package | SOT-23-5 |
| Switching Temperature | 125°C |
| Trip Temperature Threshold | Hot |
| Other | |
| Base Product Number | TC650 |
| Features | - |
| Mfr | Microchip Technology |
| Output | Active High |
| Output Function | OverTemp |
| Output Type | Push-Pull |
| Product Status | Active |
| Selectable Hysteresis | Yes |
| Series | - |
