View full reportTechnical parameters
Key specs
Capacitance220 µF
Rated voltage2.5 V
Tolerance20 %
ESR15 mΩMax · 100kHz
Lifetime2 kh105°C
| Power | |
|---|---|
| Voltage - Rated | 2.5 V |
| Environment and package | |
| Height - Seated (Max) | 0.079" (2.00mm) |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Manufacturer Size Code | B |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 105°C |
| Package / Case | 1411 (3528 Metric) |
| Size / Dimension | 0.138" L x 0.110" W (3.50mm x 2.80mm) |
| Other | |
| Capacitance | 220 µF |
| ESR (Equivalent Series Resistance) | 15mOhm @ 100kHz |
| Features | General Purpose |
| Lead Spacing | - |
| Manufacturer | KEMET |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Ratings | - |
| Series | T520 |
| Tolerance | ±20% |
| Type | Molded |
