View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 4A (AC/DC) |
| Voltage Rating | 230VAC, 24VDC |
| Voltage - Supply | - |
| Environment and package | |
| Conduit Thread Size | M20 x3 |
| Operating Temperature | -20°C~80°C |
| Package | Bulk |
| Other | |
| Actuator Type | Panel Disconnect |
| Approval Agency | CE, cULus |
| Base Product Number | T4012 |
| Circuit | DPST-NO/NC |
| Features | - |
| Holding Force | 3kgf |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Mfr | Omron Automation and Safety |
| Must Operate | - |
| Must Release | - |
| Product Status | Obsolete |
| Series | T4012 |
| Termination Style | Screw Terminal |
| Type | Non-Locking |
Documents
No documents are linked to this part yet.
