View full reportTechnical parameters
Key specs
Input voltage90 ~ 264 V
Output voltage5 V
Output current1.2 AMax
Power6 WMax
| Power | |
|---|---|
| Current - Output (Max) | 1.2A |
| No Load Power Consumption | 100mW (Max) |
| Power (Watts) | 6 W |
| Voltage - Input | 90 ~ 264 VAC |
| Voltage - Output | 5V |
| Environment and package | |
| Operating Temperature | 0°C ~ 40°C |
| Size / Dimension | 2.17" L x 0.98" W x 1.44" H (55.0mm x 25.0mm x 36.7mm) |
| Other | |
| Applications | Medical |
| Approval Agency | CB Scheme, CSA, EN, FCC, IEC, PSE, UL |
| Base Product Number | SWM6-5 |
| Cord Length | 59" (1.50m) |
| Efficiency | Level VI |
| Form | Wall Mount (Class II) |
| Input Connector | NEMA 1-15P |
| Input Type | Fixed Blade |
| Manufacturer | CUI Inc. |
| Output Connector | USB Micro |
| Packaging | Box |
| Part Status | Active |
| Polarization | - |
| Region Utilized | North America |
| Series | SWM6-N (6W) |
| Standard Number | C22.2 No. 60601-1; 55011 Class B; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 |
