Bel Fuse Inc.United States
Wall Plug Adapters
All alternatives
View full reportTechnical parameters
Key specs
Outputs1
| Power | |
|---|---|
| Input Voltage Range (VAC) | 90 ~ 264 |
| Output Current (A) | 1 |
| Output Voltage (VDC) | 5 |
| Power (W) | 5 |
| Environment and package | |
| DC Plug Type Dimensions | 5.5mm (OD), 2.1mm (ID), 9.5mm (L) |
| Dimensions L x W x H (in) | 2.64 x 1.95 x 2.55 |
| Dimensions L x W x H (mm) | 67 x 49.5 x 64.8 |
| Operating Temperature Range (ºC) | 0 ~ +40 |
| RoHS Compliant | Yes |
| Other | |
| Blade Region | United Kingdom |
| Blade Type | Fixed Blade |
| Brand | CUI |
| Color | Black |
| DC Plug Type | Barrel Plug |
| Efficiency Standards | Level VI |
| Market | ITE |
| Number of Outputs | 1 |
| Plug Angle | Straight |
| Plug Polarity | Center Positive |
| Protections | Over Current, Over Voltage, Short Circuit |
| Safety Approvals | UKCA |
| Safety Standards | 62368 |
