The SQ82550 is a high precision, micro power, low temperature drift shunt voltage reference. The utilization of package level trim technology enables the achievement of better than ±0.1% initial accuracy at 25°C. The device does not require an output capacitor to be stable but tolerates capacitive loads. The SQ82550 supports wide operating current range from IRMIN to 15mA. The SQ82550 is available in a SOT-23 package and capable of operating within a temperature range of -40 to 125°C.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Minimum operating current (max)(μA) | 97 |
| Operating current (max)(mA) | 15 |
| AC and DC characteristics | |
| Initial accuracy(max)(%) | 0.1 |
| Low frequency noise (typ)(μVpp/V) | 6.6 |
| Environment and package | |
| Operating temperature range(°C) | -40 to 125 |
| Package | SOT-23 |
| Temp coeff(max)(ppm/℃) | 38 |
| Other | |
| Vo(V) | 4.096 |
