ABSOLUTE PRESSURE SENSOR
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Voltage - Supply | 1.7V ~ 3.6V |
| AC and DC characteristics | |
| Accuracy | ±0.5% |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Package / Case | 10-FLGA |
| Port Size | - |
| Supplier Device Package | 10-LGA (2x2) |
| Other | |
| Applications | Board Mount |
| Features | Standby Mode |
| Maximum Pressure | - |
| Mfr | Goertek Microelectronics Inc. |
| Operating Pressure | 4.35 ~ 15.95PSI (30 ~ 110kPa) |
| Output | 24 b |
| Output Type | I²C, SPI |
| Port Style | No Port |
| Pressure Type | Absolute |
| Product Status | Obsolete |
| Series | - |
| Termination Style | - |
Documents
No documents are linked to this part yet.
