The SN74LVC240A-Q1 is an octal buffer with 3-state outputs. The device is configured into two banks of four drivers, each controlled by an output enable pin.
All alternatives
View full reportTechnical parameters
| Power | |
|---|---|
| Number of channels | 8 |
| Supply current (max) (µA) | 10 |
| Environment and package | |
| Operating temperature range (°C) | -40 to 125 |
| Other | |
| Features | Balanced outputs, Very high speed (tpd 5-10ns) |
| Input type | Standard CMOS |
| IOH (max) (mA) | -24 |
| IOL (max) (mA) | 24 |
| Output type | 3-State |
| Rating | Automotive |
| Technology family | LVC |
