View full reportTechnical parameters
Key specs
Input voltage90 ~ 264 V
Output voltage12 V
Output current500 mAMax
Power6 WMax
| Power | |
|---|---|
| Current - Output (Max) | 500mA |
| No Load Power Consumption | 100mW (Max) |
| Power (Watts) | 6 W |
| Voltage - Input | 90 ~ 264 VAC |
| Voltage - Output | 12V |
| Environment and package | |
| Operating Temperature | 0°C ~ 40°C |
| Size / Dimension | 2.24" L x 1.54" W x 1.34" H (57.0mm x 39.0mm x 34.0mm) |
| Other | |
| Applications | Medical |
| Approval Agency | CB Scheme, CSA, EN, FCC, IEC, UL |
| Base Product Number | SMM6-12 |
| Cord Length | 59" (1.50m) |
| Efficiency | Level VI |
| Form | Wall Mount (Class II) |
| Input Connector | Multi-Blade (Included) |
| Input Type | Multi-Blade (Included) |
| Manufacturer | CUI Inc. |
| Output Connector | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm |
| Packaging | Box |
| Part Status | Active |
| Polarization | Positive Center |
| Region Utilized | International |
| Series | SMM6 (6W) |
| Standard Number | C22.2 No. 60601-1; 55024; 55032 Class B; 60601-1; 60950-1; 61000-3-2; 61000-3-3 |
