View full reportTechnical parameters
Key specs
Reverse standoff voltage11 V
Breakdown voltage12.2 V
Clamping voltage20.1 VMax
Peak pulse power1.5 kW
PolarityUnidirectional
| Power | |
|---|---|
| Current - Peak Pulse (10/1000µs) | 78A |
| Power Line Protection | No |
| Power - Peak Pulse | 1500W (1.5kW) |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 12.2V |
| Voltage - Clamping (Max) @ Ipp | 20.1V |
| Voltage - Reverse Standoff (Typ) | 11V |
| AC and DC characteristics | |
| Capacitance @ Frequency | - |
| Environment and package | |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Package / Case | DO-214AB, SMC |
| Supplier Device Package | DO-214AB (SMC) |
| Other | |
| Applications | General Purpose |
| Base Product Number | SMCJ11 |
| Mfr | Taiwan Semiconductor Corporation |
| Packaging | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® |
| Part Status | Active |
| Series | SMCJ |
| Type | Zener |
