View full reportTechnical parameters
| Environment and package | |
|---|---|
| Package | SMA |
| Other | |
| IPP(A) | 10.4 |
| IR@VRWM(μA) | 1 |
| PPk（W） | 600 |
| Status | Active |
| Tj（℃） | -55～+175 |
| Type | Bi |
| VBR _Max(V) | 44.2 |
| VBR _Min(V) | 40 |
| VC@IPP(V) | 58.1 |
| VRWM(V) | 36 |
