View full reportTechnical parameters
Key specs
Reverse standoff voltage26 V
Breakdown voltage28.9 V
Clamping voltage42.1 VMax
Peak pulse power600 W
PolarityBidirectional
| Power | |
|---|---|
| Bidirectional Channels | 1 |
| Current - Peak Pulse (10/1000µs) | 14.3A |
| Power Line Protection | No |
| Power - Peak Pulse | 600W |
| Voltage - Breakdown (Min) | 28.9V |
| Voltage - Clamping (Max) @ Ipp | 42.1V |
| Voltage - Reverse Standoff (Typ) | 26V |
| AC and DC characteristics | |
| Capacitance @ Frequency | - |
| Environment and package | |
| Grade | Automotive |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 175°C (TA) |
| Package | Bulk |
| Package / Case | DO-214AC, SMA |
| Qualification | AEC-Q101 |
| Supplier Device Package | DO-214AC (SMA) |
| Other | |
| Applications | - |
| Base Product Number | SMA6J26 |
| Mfr | Micro Commercial Co |
| Product Status | Active |
| Series | - |
| Type | Zener |
