View full reportTechnical parameters
| Power | |
|---|---|
| Current Rating (Amps) | 1 A |
| Voltage - Rated | 12VDC |
| Environment and package | |
| Mounting Type | Surface Mount, Right Angle |
| Operating Temperature | -25°C ~ 85°C |
| Panel Hole Size | - |
| Thread Size | - |
| Other | |
| Actual Diameter | 0.102" (2.60mm) |
| Base Product Number | SJ-25 |
| Body Color | Black |
| Body Material | - |
| Cable Opening | - |
| Connector Type | Phone Jack |
| Contact Material | Copper Alloy |
| Contact Material - Plating | Gold |
| Features | - |
| Gender | Female |
| Housing Material | Polyamide (PA6T), Nylon 6T |
| Includes | - |
| Industry Recognized Mating Diameter | 2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone |
| Insulation Color | - |
| Internal Switch(s) | Does Not Contain Switch |
| Mating Length/Depth | - |
| Mfr | Same Sky |
| Number of Positions/Contacts | 3 Conductors, 3 Contacts |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Series | SJ |
| Shielding | Unshielded |
| Signal Lines | Stereo (3 Conductor, TRS) |
| Termination | Solder |
