SF

Realized high contact reliability by adopted face to face dimple structure in connecting par...

All alternatives

Pitch7.5 mm

Power
Rated Current	10A
Rated Voltage	AC.DC 300V
Withstand Voltage	AC1500V/1min
Environment and package
Mounting Style	DIP
Temperature Range	-25～+105℃
Wire Size	AWG #16～ #24
Other
742462-2MA	#20 ～ #24 \| 1.4 ～ 2.6mm \| TJS-13400 \| SCA-68500
742462-2MAC	#20 ～ #24 \| 1.4 ～ 2.6mm \| TJS-13400 \| SCA-68500
742462-2MAF	#20 ～ #24 \| 1.4 ～ 2.6mm \| TJS-13400 \| SCA-68500
742764-2MA	#16 ～ #20 \| 1.7 ～ 3.1mm \| TJS-13500 \| SCA-71200
742764-2MAC	#16 ～ #20 \| 1.7 ～ 3.1mm \| TJS-13500 \| SCA-71200
Applicable P.C.B. Hole dia.	1.7mm
Applicable P.C.B. Thickness	1.2～1.6mm
for Crimping Machine	for Strip Crimper
Insulation Resistance	1000MΩover
Pitch	7.5mm
Pitch (mm)	7.5
Poles	Single:2・3・4P
Terminal No.	Wire Size \| Dia of Insulation \| Applicator
