C&KUnited States
SWITCH SLIDE DIP SPST 100MA 25V
All alternatives
View full reportTechnical parameters
Key specs
CircuitSPST
Current rating100 mAMax
| Power | |
|---|---|
| Current Rating (Amps) | 100mA |
| Voltage Rating | 25VDC |
| Environment and package | |
| Height Above Board | 0.178" (4.52mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -40°C~85°C |
| Package | Tube |
| Other | |
| Actuator Level | Flush, Recessed |
| Actuator Type | Slide (Standard) |
| Base Product Number | SD12H0 |
| Body Material | Polyphthalamide (PPA) |
| Circuit | SPST |
| Contact Finish | Gold |
| Contact Material | Beryllium Copper |
| Electrical Life | 2,000 Cycles |
| Features | Tape Seal |
| Length | 1.258" (31.95mm) |
| Mechanical Life | 2,000 Cycles |
| Mfr | C&K |
| Number of Positions | 12 |
| Pitch | 0.100" (2.54mm), Full |
| Product Status | Active |
| Series | SD |
| Termination Style | PC Pin |
| Washable | Yes |
