View full reportTechnical parameters
| Power | |
|---|---|
| Current - Test | 20mA |
| Power Dissipation (Max) | 600mW |
| Voltage - Forward (Vf) (Typ) | 7.4V |
| Environment and package | |
| Digit/Alpha Size | 3.98" (101.20mm) |
| Package / Case | 10-DIP (4.210", 107.00mm) |
| Size / Dimension | 4.803" H x 3.543" W x 0.591" D (122.00mm x 90.00mm x 15.00mm) |
| Other | |
| Base Product Number | SC40-19 |
| Color | Red |
| Common Pin | Common Cathode |
| Display Type | 7-Segment |
| Manufacturer | Kingbright |
| Millicandela Rating | 110mcd |
| Number of Characters | 1 |
| Packaging | Tube |
| Part Status | Obsolete |
| Series | - |
| Wavelength - Peak | 660nm |
