Key specs
Frequency13 MHz
Frequency tolerance30 ppm
Load capacitance12 pF
ESR60 ΩMax
| AC and DC characteristics | |
|---|---|
| Frequency | 13 MHz |
| Frequency Stability | ±50ppm |
| Frequency Tolerance | ±30ppm |
| Environment and package | |
| Height - Seated (Max) | 0.035" (0.90mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~125°C |
| Package | Tape & Reel (TR) |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.197" L x 0.126" W (5.00mm x 3.20mm) |
| Other | |
| ESR (Equivalent Series Resistance) | 60 Ohms |
| Load Capacitance | 12pF |
| Mfr | CTS-Frequency Controls |
| Operating Mode | Fundamental |
| Product Status | Active |
| Ratings | AEC-Q200 |
| Series | SA534 |
| Type | MHz Crystal |
