Key specs
Frequency19.68 MHz
Frequency tolerance30 ppm
Load capacitance10 pF
ESR200 ΩMax
| AC and DC characteristics | |
|---|---|
| Frequency | 19.68 MHz |
| Frequency Stability | ±50ppm |
| Frequency Tolerance | ±30ppm |
| Environment and package | |
| Height - Seated (Max) | 0.020" (0.50mm) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C |
| Package | Tape & Reel (TR) |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.079" L x 0.063" W (2.00mm x 1.60mm) |
| Other | |
| ESR (Equivalent Series Resistance) | 200 Ohms |
| Load Capacitance | 10pF |
| Mfr | CTS-Frequency Controls |
| Operating Mode | Fundamental |
| Product Status | Active |
| Ratings | AEC-Q200 |
| Series | SA204 |
| Type | MHz Crystal |
