Key specs
Rated current800 mA
Rated voltage250 V
Response timeSlow
Breaking capacity100 A
| Power | |
|---|---|
| Breaking Capacity @ Rated Voltage | 100A |
| Current Rating (Amps) | 800 mA |
| Voltage Rating - AC | 250 V |
| Environment and package | |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 125°C |
| Package / Case | Radial, Box |
| Size / Dimension | 0.329" L x 0.157" W x 0.303" H (8.35mm x 4.00mm x 7.70mm) |
| Other | |
| Approval Agency | CCC, CE, cULus, SEMKO, VDE |
| Color | - |
| DC Cold Resistance | 0.095 Ohms |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 4.2 |
| Mfr | Bel Fuse Inc. |
| Packaging | Tape & Box (TB) |
| Part Status | Obsolete |
| Response Time | Slow Blow |
| Series | RST |
